Drip Edge Roll Forming Machines

Roll Forming Machines LLC supplies a variety of drip edge roll forming machines for roofing and cladding applications. We offer machines that produce standard profiles like FHA, C, and F shapes, as well as fully custom profiles based on your needs. Machines are available for single-profile or side-by-side production setups.

We provide both standard machines running at 50 feet per minute and high-speed options up to 150 feet per minute, ideal for higher volume production.

All machines include a one-year parts and labor warranty and are shipped from our Orlando, Florida facility, where we keep stocked machines for quick delivery. You’re welcome to visit our Orlando site to view machines and discuss your production requirements.

For more details or to arrange a visit, please contact us at [email protected] or (+1) (407) 859 1119. We look forward to assisting you.

Machine Specifications

Production Speed: Standard: 50 - 80 feet per minute
High-Speed Option: Up to 150 feet per minute
Roll Stations: 8 to 12 stations (based on profile complexity)
Machine weight: 6000lbs -
Machine size: Based on standard machine 18ft x 3ft x 5ft
Drive System: Chain-driven or gearbox-driven
Cutting System: Hydraulic or flying shear
Control System: PLC control with touch screen Programmable length and batch quantity
Power Supply: Typically 240V / 3-phase, 60Hz
Motor Power: 3 – 7.5 kW depending on machine size and speed
Machine Frame: Heavy-duty steel frame, welded construction
Roller Material: High-grade steel (GCr15), hardened and chrome-coated
Length Tolerance: ±1.5 mm
Optional Features: Side-by-side tooling for multiple profiles,
Safety Features: Emergency stop buttons, Protective covers
Warranty: 12 months parts and labor

Interested? Contact us today and get a quote on a machine!

If you have any questions, don't hesitate to ask. Our expert team is always ready to answer any questions you have. If you are interested in viewing one of our machines in person, you can visit our factory at 10895 Rocket Blvd, Orlando, FL 32824, USA
